Specifications

Image Sensor

1. Type
2. Approx. 22.3 × 14.9 mm (APS-C) CMOS
3. Effective Pixels
4. 24.2MP
5. Total Pixels
6. 25.5MP
7. Aspect Ratio
8. 3:2
9. Low-Pass Filter
10. Built-in/Fixed
11. Sensor Cleaning
12. Not provided
13. Colour Filter Type
14. RGB Primary Colour
15. Sensor Shift-IS
16. No

Image Processor

1. Type
2. DIGIC X

Lens

1. Lens Mount
2. RF (natively supporting RF and RF-S lenses) EF and EF-S lenses can be attached using Mount Adapter EF-EOS R, EF-EOS R Control Ring Mount Adapter, Drop-in Filter Mount Adapter EF-EOS R EF-M lenses are not compatible1
3. Focal Length
4. Equivalent to 1.6x the focal length of the lens with RF/RF-S and EF/EF-S lenses
5. Image Stabilisation
6. Lens / Digital only

Focusing

1. Type
2. Dual Pixel CMOS AF II
3. AF System / Points
4. 100% horizontal and 100% vertical (Auto selection) 90% horizontal and 100% vertical (Manual selection) Max. 651 zones / 4503 positions for stills Max. 527 zones / 3713 positions for movies2
5. AF Working Range
6. EV -4 – 20 (at 23°C & ISO100)3
7. AF Modes
8. One Shot Servo AF Auto Switch (only in A+ mode)
9. AF Point Selection
10. Automatic selection: 651 Available AF areas when automatically selected Manual selection: 1-point AF (AF frame size can be changed) 4503 AF positions available stills (3713 Movies) Manual selection: AF point Expansion 4 points (up, down, left, right) Manual selection: AF point Expansion surrounding Manual selection: Flexible Zone AF 1-3 (all AF points divided into minimum 9 to 513 maximum focusing zones) Manual selection: Whole Area AF (Entire focusing area with 651 maximum focusing zones)
11. AF Tracking
12. Humans (Eyes/Face/Head/Body), Animals (Dogs, Cats and Birds) or Vehicles (Racing cars or Motor bikes)
13. AF Lock
14. Locked when: - shutter button is pressed halfway - customised button set to Metering and AF start is pressed in One Shot AF mode. - Using customised button set to AF stop in AI servo
15. AF Assist Beam
16. Emitted by built in LED or optional dedicated Speedlite (flash)
17. Manual Focus
18. Selected on lens / in camera menu for lenses without AF / MF switch4

Exposure Control

1. Metering Modes
2. Real-time with image sensor, 384-zone metering. (1) Evaluative metering (linked to All AF points) (2) Partial metering (Approx. 5.8% of viewfinder at centre) (3) Spot metering: Centre spot metering (Approx. 2.9% viewfinder at centre) AF point-linked spot metering not provided (4) Centre weighted average metering
3. Metering Brightness Range
4. Stills: EV -2 to 20 (at 23°C, ISO100, with evaluative metering) Movies: EV 0 to 20 (at 23°C, ISO100, with evaluative metering)
5. AE Lock
6. Auto: AE lock takes effect when focus is achieved Manual: By AE lock button in P, Av, Fv, Tv and M modes. Press again to cancel and once more to refresh. Enabled in all metering modes
7. Exposure Compensation
8. +/-3 EV in 1/3 stop increments (can be combined with AEB)
9. AEB
10. +/-3 EV in 1/3 stop increments
11. Anti-flicker Shooting
12. Yes. Flicker detected at a frequency of 100 Hz or 120 Hz High frequency anti-flicker shooting not provided5
13. ISO Sensitivity Open Close Recommended Exposure Index
14. Auto 100-32000 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 512006

Shutter

1. Type
2. Electronically controlled focal-plane shutter and Electronic rolling shutter function using the image sensor7
3. Speed
4. Mechanical: 30-1/4000 sec (1/3 stop increments), Bulb Electronic: 30-1/8000 (1/3 stop increments), Bulb
5. Shutter Release
6. Soft-touch electromagnetic release

White Balance

1. Type
2. Auto white balance with the imaging sensor AWB (Ambience priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting
3. Settings
4. White balance shift:8 1. Blue/Amber +/-9 2. Magenta/Green +/-9
5. Custom White Balance
6. Yes, 5 setting can be registered by selecting an image on card
7. WB Bracketing
8. +/- 3 levels (in single-level increments) Selectable Blue/Amber bias or Magenta/Green bias

Viewfinder

1. Type
2. 0.39 inch OLED colour EVF
3. Dot Count
4. 2.36 Million dots (1024x768)
5. Coverage (Vertical/Horizontal)
6. Approx. 100%9
7. Magnification
8. Approx. 0.95x10
9. Eyepoint
10. Approx. 22mm (At -1 m-1 from eyepiece lens end)
11. Dioptre Correction
12. -3 to +1 m-1 (dioptre)
13. Display Performance
14. Power saving: 59.94 fps Smooth: 119.98 fps11
15. Viewfinder Information
16. Stills: Grid display (Off / 3x3 / 6x4 / 3x3 + diagonal), Histogram display (Brightness / RGB, Large / Small), Focus distance display, Focal length display, SA variable amount12 Movies: Grid display (Off / 3x3 / 6x4 / 3x3 + diagonal), Histogram display (Brightness / RGB, Large / Small), Focus distance display, Focal length display, SA variable amount, Recording emphasis, aspect marker (Off / 1:1 / 4:5 / 5:4 / 9:16 / 4:3 / 13:9 / 14:9 / 1.375:1 / 1.66:1 / 1.75:1 / 1.85:1 / 1.90:1 / 2.35:1 / 1.39:1)
17. Depth of Field Preview
18. Yes, via customised button and when display simulation is set to Exposure+DOF
19. Eyepiece Shutter
20. Not provided

LCD Monitor

1. Type
2. Approx. 7.5 cm (2.95") TFT colour LCD monitor, Approx. 1.62 million dots
3. Coverage
4. Approx. 100%13
5. Viewing Angle (Horizontally/Vertically)
6. Approx. 170° vertically and horizontally
7. Coating
8. None
9. Brightness Adjustment
10. Manual: Adjustable to one of seven levels Colour Tone Adjustment: Not supported
11. Touch Screen Operations
12. Capacitive method with menu functions, Quick Control settings, playback operations, and magnified display. AF point selection in still and Movies, touch shutter is possible in still photo shooting.14
13. Display Options
14. (1) Basic Camera settings (2) Advance Camera settings (3) Camera settings plus histogram and dual level display (4) No info (5) Quick Control Screen

Flash

1. Built-in Flash GN (ISO 100, meters)
2. 6
3. Built-in Flash Coverage
4. Approx. 18 mm focal length/angle of view (35mm equivalent: approx. 29 mm)
5. Built-in Flash Recycle Time
6. Approx. 5 sec.
7. Modes
8. E-TTL II Auto Flash, Metered Manual
9. Red-Eye Reduction
10. Supported
11. X-Sync
12. 1/250 sec. electronic 1st curtain Flash photography is not available with Electronic shutter.
13. Flash Exposure Compensation
14. +/- 3EV in 1/3 increments with EX series Speedlite flashes +/- 2EV in 1/3-stop increments with built in flash
15. Flash Exposure Bracketing
16. Yes, with compatible External Flash (+/- 3EV in 1/3- or 1/2-stop increments with EX/EL series Speedlite flashes)
17. Flash Exposure Lock
18. Yes
19. Second Curtain Synchronisation
20. Yes, (With both the built-in and external Speedlites)15
21. HotShoe / PC Terminal
22. Hot shoe: 21-pin multi-function shoe only PC Terminal: No16
23. External Flash Compatibility
24. E-TTL II with EX/EL series Speedlite, wireless multi-flash support
25. External Flash Control
26. via camera menu screen

Shooting

1. Modes
2. Scene Intelligent Auto (A+ Assist): Creative Assist, Creative bracketing, Advanced A+ Hybrid Auto: Digest Movie Scene17: Self Portrait, Portrait, Smooth skin, Group photos, Landscape, Panoramic shot18, Sports, Kids, Panning19, Close-up, Food20, Handheld Night Scene21, HDR Backlight Control, Silent shutter22 Creative filters23: Grainy B/W, Soft focus, Fish-eye effect, Water painting effect, Toy camera effect, Miniature effect, HDR art standard, HDR art vivid, HDR art bold, HDR art embossed P: Program Tv: Shutter-priority AE Av: Aperture-priority AE M: Manual exposure, bulb exposure Movie: Movie auto exposure, Movie manual exposure, Movie for close-up demos, Movie IS mode, HDR movie, Movie auto exposure
3. Picture Styles
4. Auto, Standard, Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined (x3)
5. Colour Space
6. sRGB and Adobe RGB / Fixed at HDR PQ
7. Image Processing
8. Resize JPEG / HEIF images to M, S1, S2 Cropping: JPEG / HEIF images can be cropped (Aspect ratios 3:2, 4:3, 16:9, 1:1) Cropping of images - Switch between vertical and horizontal cropping orientation - Cropping frame can be moved using touch screen operation RAW image processing: not supportsed HDR HEIF to Jpeg conversion Lens optical correction: - Peripheral illumination correction, Chromatic aberration correction, Distortion correction (during/after still photo shooting, during video only) - Diffraction correction, Digital Lens Optimizer (during/after still photo shooting) Focus breathing compensation (compatible lenses, movies only) Highlight Tone Priority (3 settings) Auto Lighting Optimizer (4 settings) Long exposure noise reduction (3 settings) High ISO speed noise reduction (4 settings) (still and video) Clarity (+/- 4)
9. Drive Modes
10. Single, Continuous High+, Continuous High, Continuous Low, Self-timer (2s+remote, 10s+remote, continous)
11. Continuous Shooting
12. Max. Approx. 12 FPS with Mechanical shutter/1st curtain electronic shutter the speed maintained for 42 JPEG or 7 RAW images Max. Approx. 15 FPS with Electronic shutter the speed maintained for 28 JPEG or 7 RAW images24
13. Interval Timer
14. Built in: 3 Scenes (moving subjects, slowly changing subjects, slowly changing scenes), Custom

File Type

1. Still Image Type
2. RAW 14 bit: RAW and C-RAW (Canon original RAW 3rd edition) JPEG 8 bit: 2 compression options HEIF 10 bit: 2 compression options Complies with Exif 2.31 and Design rule for Camera File system 2.0 Complies with Digital Print Order Format [DPOF] Version 1.125
3. RAW+JPEG Simultaneous Recording
4. Yes, any combination of RAW + JPEG or RAW + HEIF possible
5. Image Size
6. RAW/ C-RAW: 6000x4000 (3:2 aspect ratio) JPEG/ HEIF: 3:2 ratio (L) 6000x4000, (M) 3984x2656, (S1) 2976x1984, (S2) 2400x1600 4:3 ratio (L) 5328x4000, (M) 3552x2664, (S1) 2656x1992, (S2) 2112x1600 16:9 ratio (L) 6000x3368, (M) 3984x2240, (S1) 2976x1680, (S2) 2400x1344 1:1 ratio (L) 4000x4000, (M) 2656x2656, (S1) 1984x1984, (S2) 1600x1600
7. Folders
8. New folders can be manually created and selected
9. File Numbering
10. (1) Continuous numbering (2) Auto reset (3) Manual reset
11. File Naming
12. Not supported

EOS Movie

1. Movie Type
2. HDR PQ [OFF]: MP4, 8 bits, H.264 / MPEG-4 AVC, YCbCr 4:2:0, Rec.709, AAC HDR PQ [ON]: MP4, 8 bits, H.265 / HEVC, YCbCr 4:2:2, Rec.2020, AAC
3. Movie Size
4. 4K UHD26: 3840 x 2160, 16:9, NTSC (29.97 / 23.98) / PAL (25.00), IPB (Standard / Light), AAC Full HD High Frame Rate Movies: 1920 x 1080, 16:9, NTSC (119.88) / PAL (100.00), IPB (Standard / Light), No audio Full HD: 1920 x 1080, 16:9, NTSC (59.94 / 29.92 / 23.98) / PAL (50.00 / 25.00), IPB (Standard / Light), AAC, Digital Zoom 1-10x available at 29.97 / 23.98 / 25.00 Full HD time-lapse27 movies: 1920 x 1080, 16:9, NTSC (29.97) / PAL (25.00), ALL-I, No audio28 HDR movies: 1920 x 1080, 16:9, NTSC (29.97) / PAL (25.00), IPB (Standard), AAC Creative filters: 1920 x 1080, 16:9, NTSC (29.97 / 23.98) / PAL (25.00), IPB (Standard / Light), AAC
5. Colour Sampling (Internal Recording)
6. 4K UHD / Full HD - YCbCr4:2:0 8-bit or YCbCr4:2:2 10bit (when HDR PQ is enabled)
7. Canon Log
8. Not supported
9. Movie Length
10. Max duration 1 hour (excluding High Frame Rate movies). No 4 GB file limit with exFAT formatted card.29
11. High Frame Rate Movie
12. Full HD 1920 x 1080 at 100 fps or 119.9 fps Recorded as 1/4-speed slow motion movie30
13. Frame Grab
14. 8.3-megapixel JPEG still image frame grab from 4K UHD movie possible31 (HEIF only possible when HDR PQ is set)
15. Bitrate / Mbps
16. MOV: MP4 HDR PQ: Off: 4K UHD (29.97p/25.00p/23.98p): IPB Approx. 120 Mbps 4K UHD (29.97p/25.00p/23.98p): IPB Light Approx. 60 Mbps Full HD (119.9p / 100p): IPB Approx. 120 Mbps Full HD (119.9p / 100p): IPB Light Approx. 70 Mbps Full HD (59.94p/50.00p): IPB Approx. 60 Mbps Full HD (59.94p/50.00p): IPB light Approx. 35 Mbps Full HD (29.97p/25.00p/23.98p): IPB Approx. 30 Mbps Full HD (29.97p/25.00p/23.98p): IPB Light Approx. 12 Mbps Full HD Time-lapse (29.97p/25.00p): ALL-I Approx. 90 Mbps MOV: MP4 HDR PQ: On 4K UHD (29.97p/25.00p/23.98p): IPB Approx. 170 Mbps 4K UHD (29.97p/25.00p/23.98p): IPB Light Approx. 85 Mbps Full HD (119.9p / 100p): IPB Approx. 180 Mbps Full HD (119.9p / 100p): IPB Light Approx. 100 Mbps Full HD (59.94p/50.00p): IPB Approx. 90 Mbps Full HD (59.94p/50.00p): IPB light Approx. 50 Mbps Full HD (29.97p/25.00p/23.98p): IPB Approx. 45 Mbps Full HD (29.97p/25.00p/23.98p): IPB Light Approx. 28 Mbps Full HD Time-lapse (29.97p/25.00p):ALL-I Approx. 135 Mbps
17. Dual Card Recording
18. Not supported
19. Microphone
20. Built-in stereo microphone (48 KHz, 16-bit x 2 channels)
21. HDMI Display
22. Output to external monitor only (output of images and shooting information, images/video are recorded to the card) Camera screen and External Monitor output (Recording to camera is not possible, use with external recorder, camera screen shows images with shooting information)
23. HDMI Output
24. HDMI Micro OUT terminal (Type D)32 Auto: - 4K (UHD): NTSC (29.97p / 25.00p), PAL (23.98p) - 1080 NTSC (59.94p / 59.94i), PAL (50.00p / 50.00i) - 480 NTSC (59.94p) - 576 PAL (50.00p) 1080p: - 1080 NTSC (59.94p / 59.94i), PAL (50.00p / 50.00i) - 480 NTSC (59.94p) - 576 PAL (50p) HDR Specification: Rec. ITU-R BT.2100 (PQ) Bit depth: 10 bits Colour sampling method: Uncompressed YCbCr 4:2:2 Colour space: BT.709 / BT.601 / BT.2020 / BT.2100
25. Focusing
26. Dual Pixel CMOS AF II with Eye/Face Detection and Tracking AF (people, animals and vehicles) , Movie Servo AF, Manual Focus
27. ISO
28. Auto: 100-12800, H: 25600 Manual: 100-12800, H: 16000-25600

Other Features

1. Custom Functions
2. 6 Custom Functions ISO expansion Safety shift Customize buttons Customize control ring Release shutter without lens Retract lens on power off
3. Metadata Tag
4. User copyright information (can be set in camera)
5. LCD Panel / Illumination
6. Not provided
7. Water/Dust Resistance
8. Not provided
9. Voice Memo
10. Not provided
11. Intelligent Orientation Sensor
12. Yes
13. Playback Zoom
14. 1.5x - 10x in 15 steps
15. Display Formats
16. (1) Single image (2) Single image with information (basic / detailed) (3) 4 image index (4) 9 image index (5) 36 image index (6) 100 image index (7) Jump Display (1, 10 or Custom (1-100) images, Date, Folder, Movies, Stills, Protected images, Rating, Jump to first image of scene) (8) Rating
17. SlideShow
18. Image selection: All images Playback time: 1/2/3/5/10 or 20 seconds Repeat: On/Off Transition effect: Off / Slide in 1 / Slide in 2 / Fade 1 / Fade 2 / Fade 3
19. Histogram
20. Brightness: Yes RGB: Yes
21. Highlight Alert
22. Not provided
23. Image Erase
24. Single image, select range, Selected images, Folder, Card
25. Image Erase Protection
26. Protect / Unprotect: Single image, Folder, Card, All found images
27. Self Timer
28. 2sec, 10 sec
29. Menu Categories
30. (1) Shooting menu (2) AF Menu (3) Playback menu (4) Network (5) Setup menu (6) Custom Functions menu (7) My Menu
31. Menu Languages
32. 29 Languages English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean, Malay, Indonesia and Japanese
33. Firmware Update
34. Update possible by the user (Camera, Lens, External Speedlite, BLE remote control, Lens adapter, multi-function shoe accessories)

Interface

1. Computer
2. Hi-Speed USB 2.0 USB Type-C connector For computer communication / smartphone communication / battery charging / camera power supply
3. Other
4. HDMI Micro out (Type D, HDMI-CEC not supported) External Microphone In (3.5mm Stereo mini jack)

Direct Print

1. Canon Printers
2. Canon Compact Photo Printers and PIXMA Printers supporting PictBridge via wireless LAN
3. PictBridge
4. Yes (via Wireless LAN)

Storage

1. Type
2. SD/SDHC/SDXC and UHS-I33

Supported Operating System

1. PC
2. Windows 10/11 (Desktop mode only)34
3. Macintosh
4. macOS 10.15, 11.4, 12, 13

Software

1. Image Processing
2. Digital Photo Professional 4.17.20. or later, Digital Photo Professional Express mobile app (iOS only v1.8.10. or later) (RAW Image Processing not DUAL PIXEL RAW on DPP Express mobile)
3. Other
4. EOS Utility# 3.16.10 or later (incl. Remote Capture), Picture Style Editor 1.28.10 or later, EOS Lens Registration Tool, Canon Camera connect app 3.0.10 or later (iOS/Android)35

Power Source

1. Batteries
2. Rechargeable Li-ion Battery LP-E17 (supplied)36
3. Battery Life
4. With LCD Approx. 440 shots (at 23°C) With Viewfinder Approx. 310 shots (at 23°C)37
5. Battery Indicator
6. 4 level indicator
7. Power Saving
8. Screen dimmer: 5 sec. / 10 sec. / 15 sec. / 20 sec. /25 sec. / 30 sec. / Disable Screen off38: 5 sec. / 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. / Disable Auto power off: 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. / Disable Viewfinder off: 1 min. / 3 min. / Disable
9. Power Supply & Battery Chargers
10. Battery charger LC-E17E (supplied), AC Adapter AC-E6N and DC Coupler DR-E18, PD-E1 USB power adapter

Accessories

1. Wireless File Transmitter
2. None
3. Cases / Straps
4. Strap provided Hand Strap E2
5. Lenses
6. All RF and RF-S lenses (EF & EF-S via Lens adapters)
7. Lens Adapters
8. Mount Adapter EF-EOS R, EF-EOS R Control Ring Mount Adapter, Drop-in Filter Mount Adapter EF-EOS R
9. Flash
10. Canon Speedlite EL-5, Speedlite Transmitter ST-E10 With AD-E1 adapter: Canon Speedlite (EL-1, EL-100, 90EX, 220EX, 270EX, 270EX II, 320EX, 380EX, 420EX, 430EX, 430EX II, 430EX III 470EX-AI, 550EX, 580EX, 580EX II, 600EX, 600EX-RT, 600EX-II-RT, Macro-Ring-Lite MR-14EX, Macro Ring Lite MR-14EX II, Macro Twin Lite MT-24EX, Macro Twin Lite MT-26EX-RT, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT, Speedlite Transmitter ST-E3-RT V2, Off-Camera Shoe Cord OC-E3)
11. Remote Controller / Switch
12. Not supported39
13. Other
14. Shoe cover ER-SC2 (Included), Multi-Function Shoe Adapter AD-E1, Multi-Function Shoe Directional Stereo Microphone DM-E1D, Multi-Function Shoe Adapter for Smartphone Link AD-P1 for Android, Tripod grip HG-100TBR*, Interface Cable IFC-100U, Interface Cable IFC-400U, Protecting Cloth PC-E1 / E2 With AD-E1 adapter: Stereo Microphone DM-E1 / DM-E10040

Physical Specifications

1. Body Materials
2. Primarily consists of aluminium alloy and high-strength engineering plastic
3. Operating Environment
4. 0 – 40 °C, 85% or less humidity
5. Dimensions (W x H x D)
6. Approx. 116.3 x 85.5 x 68.8 mm
7. Weight (Body Only)
8. Black: Approx. 328 g (375g with card and battery, Based on CIPA guidelines.) White: Approx. 329 g (376g with card and battery, Based on CIPA guidelines.)
